Description
As it known to all,the S mount M12 lens normally come with distortion at least 40% -101%,
non-distortion lens provides you a real and perfect image.
- NON-Distortion Lens
- 4K Ultra resolution
- Wide angle at 4mm
- M12/S mount
- Full Glass to assure stable performance
|
SPECIFICATIONS |
|||
| Model Number | ID0428MBHR | ||
| Imager Size: | 1/1.8" | ||
| Mount Type: | M12 | ||
| Focal-Length: | 4mm | ||
| Aperture Range: | F2.8 | ||
| Field of View ： ( DxHxV) | D | 92.4° | |
| H | 74.5° | ||
| V | 54° | ||
| M.O.D: | 0.3m | ||
| Distortion(%) | -3% | ||
| CRA | 21° | ||
| Optic TTL | 5.7mm in air | ||
| Mechanical BFL | 5.47mm in air | ||
| Iris Operation : | Fixed | ||
| Resolution | 8Mega Pixel | ||
| Dimension(mm): | Φ20×25.82 | ||
| Optical Element | 9G | ||
| IR Correction | YES | ||
